●40CR淬火強度高、韌性佳
●高標準傘齒和頂蓋鍛打件生產技術
●噴塑外觀品質優異
●滾壓絲桿品質一流，使用壽命長
●精打細作鍛打銅螺母
| 型號 | 起升重量(T) | 最低離度 | 起升離度 | 裝箱數屋 | 毛重/凈重 | 尺寸 |
| QL3.2 | 3.2 | 200 | 110 | 5 | 21/20 | 67.5x27x17.5 |
| QL5 | 5 | 250 | 130 | 4 | 23/22 | 58x30x19 |
| QL8 | 8 | 260 | 140 | 4 | 27/26 | 64x33.5x19 |
| QL10 | 10 | 280 | 150 | 4 | 27/26 | 64x33.5x19 |
| QLD10 | 10 | 200 | 75 | 4 | 32/31 | 67.5x27x17.5 |
| 0L16 | 16 | 320 | 180 | 2 | 20/19 | 36.5x36x20 |
| QLD20 | 20 | 225 | 90 | 2 | 19/18 | 36.5x36x20 |
| QL20 | 20 | 325 | 180 | 2 | 22.5/21.5 | 36.5x36x20 |
| QL25 | 25 | 275 | 130 | 2 | 21/20 | 36.5x36x20 |
| QL32 | 32 | 390 | 200 | 2 | 31.5/30.5 | 43.5x42.5x23 |
| QLD32 | 32 | 320 | 180 | 2 | 35.5/34.5 | 43x38x21.5 |
| OL50 | 50 | 452 | 250 | 1 | 26.5/25.5 | 49.5x34x26.5 |
| QLD50 | 50 | 330 | 150 | 1 | 31.5/30 | 49.5x34x26.5 |
| QL100 | 100 | 452 | 200 | 1 | 66.5/63.5 | 52x36.5x38.5 |
